Product details:

S

Size: 003-005-010-020-030-050-100
Power up to 9,2 kW
Housings made of G200 gray cast iron
Quiet, no vibration
Adjustment sensitivity: 0,5 rpm

Painted with RAL 5010 blue epoxy-polyester powder

TXF

Size: 002-005-010
Power up to 2,2 kW
Housings in cast aluminum alloy
Quiet, no vibration
Adjustment sensitivity: 0,5 rpm

Painted with RAL 5010 blue epoxy-polyester powder

VH

Variator size: 003-005-010-020-030-050-100
In combination with helical gearbox: 030-040-050-060-080-100-125
Power up to 9,2 kW
Torque value max 5.000 Nm

Painted with RAL 5010 blue epoxy-polyester powder

VHA

Variator size: 002-005-010
Together with helical gearbox: A30-A40-A50-A60
Power up to 2,2 kW
Housings in cast aluminum alloy
Torque value: max 480 Nm

Painted with RAL 5010 blue epoxy-polyester powder

S + NMRV

S together with worm gearbox: 030-040-050-063-075-090-105-110-130-150
Power up to 9,2 kW
Torque value: max 2,670 Nm

Painted with RAL 5010 blue epoxy-polyester powder

TXF + NMRV

TXF together with worm gearbox: 030-040-050-063-075-090-105-110-130
Power līdz 2,2 kW
Housings in cast aluminum alloy
Torque value: max 1.100 Nm

Painted with RAL 5010 blue epoxy-polyester powder
