Tape clamps

The clamps are made according to the European DIN 3017 standard and are made of galvanized steel or stainless steel (SS). Classified according to material properties W1, W2, W3, W4 and W5.

W1 - fully galvanized steel;

W2 - strip and housing made of stainless steel (ASI 430; DIN1.4016), bolt made of galvanized steel;

W3 - completely stainless steel (ASI 430; DIN1.4016);

W4 - completely stainless steel (ASI 304; DIN1.4301);

W5 - completely stainless steel (ASI 316; DIN1.4401);

Kods

 Clamping limits, mm
Width, mm
MPC-17-19 17-19

18

MPC-20-22

 20-22 18
MPC-23-25 23-25

18

MPC-26-28

 26-28 18
MPC-29-31 29-31

20

MPC-32-35

 32-35 20
MPC-34-37 34-37

20

MPC-36-39

 36-39 20
MPC-40-43 40–43

20

MPC-44-47

 44–47 22
MPC-48-51 48–51

22

MPC-52-55

 52–55 22
MPC-56-59 56–59

22

MPC-60-63

 60-63 22
MPC-64-67 64–67

22

MPC-68-73

 68–73 24
MPC-74-79 74–79

24

MPC-80-85

 80-85 24
MPC-86-91 86-91

24

MPC-92-97

 92-97 24
MPC-98-103 98-103

24

MPC-104-112

104-112

24

MPC-113-121

 113-121 24
MPC-122-130 122-130

24

MPC-131-139

 131–139 26
MPC-140-148 140-148

26

MPC-149-161

 149-161 26
MPC-162-174 162–174

26

MPC-175-187

 175-187 26
MPC-188-200 188-200

26

MPC-201-213

 201-213 26
MPC-214-226 214-226

26

MPC-227-239

 227-239 26
MPC-240-252 240-252

26
